Laser Displacement Monitor (Laser + Tilt Angle) Kit

Long-distance laser displacement monitor

Brand: Sheng Bolan

Model: BF-YZ3.0

  In response to the recent surge in natural disasters both domestically and internationally, and the ongoing threat to the safety of rescue teams posed by secondary collapses of buildings during search-and-rescue operations, our company has invested heavily in research and testing to independently develop a specialized alarm system designed to provide early warnings of potential hazards such as loosening and collapse of walls caused by aftershocks or explosions, sinking of building beams, lateral displacement of metal containers, or collapse of glass walls. This system immediately triggers an alarm at the very first sign of movement, promptly alerting rescue personnel to evacuate to a safe zone, thereby effectively safeguarding their personal safety.

The laser displacement monitor features a harmless laser design that enables continuous, long-distance monitoring of even the slightest movements in unstable structures or buildings. When the monitored object shifts, the device immediately triggers an audible and visual alarm, alerting rescue personnel to evacuate quickly.

This alarm system is designed to provide early warnings of potential hazards such as wall loosening and collapse caused by aftershocks or explosions, sinking of building beams, lateral displacement of metal containers, or collapse of glass walls. It immediately triggers an alarm as soon as any object begins to move, alerting rescue personnel to evacuate to a safe area as quickly as possible and effectively safeguarding their personal safety.

1. Host: Laser range: 100 meters; the laser emitter can detect displacements as small as 1 mm. The host features laser spot focusing for precise positioning. The laser host comes with a built-in 4-inch display screen, and its on-board buttons allow you to zoom in or out on the displayed image by up to 36 times, with an image resolution of 5 million pixels.

2. Tilt Displacement Alarm: The tilt alarm features a built-in 0.96-inch display screen, with a tilt measurement range of 0-180 degrees. It can display the magnitude of the alarm value, which is set at 1°. It also includes a low-voltage indicator and has a continuous operating time of 24 hours.

3. Remote wireless alarm: Sound-and-light alarm; alarm brightness: 960 lumens; alarm volume: 100 dB;联动 function: Can simultaneously receive laser and tilt-angle alarms, and uses a voice播报 function to distinguish the source of the alarm signal.
